The Transgenic Mice of Regeneron

By Stoyan Radkov and Daniel Finnegan

Radkov is Of Counsel, and Finnegan is the lead Patent Attorney with Dunlap Bennett & Ludwig.

At a recent campaign stop, President Trump informed supporters that he “felt like Superman” after his experimental COVID-19 treatment with a Regeneron Pharmaceuticals Inc. antiviral drug.

The antiviral drug may have resulted from scientific experiments on a mouse, a transgenic mouse.  This mouse may have found itself in the middle of precedent-rewinding litigation before the UK, specifically, Regeneron Pharmaceuticals Inc v. Kymab Ltd.

In Regeneron Pharmaceuticals Inc v. Kymab Ltd., the UK Supreme Court overturned a decision from the Court of Appeal to find two of Regeneron’s transgenic mouse EP/UK patents invalid because they were insufficient. This judgment has returned the bar on sufficiency requiring support for practically every embodiment.

The patents in question were in the name of Regeneron Pharmaceuticals Inc (Regeneron): EP/UK1360287 and EP/UK2264163. The two patents described and claimed transgenic mice capable of producing humanized antibodies.  Regeneron alleged infringement by Kymab Ltd (Kymab). Kymab counterclaimed invalidity, on the grounds of among others, lack of sufficiency.

At the High Court, the patents were held infringed but invalid.  The Court of Appeal overturned the decision on validity finding that the patents were valid and infringed. Kymab appealed to the Supreme Court.

STATE OF THE ART

At the relevant date, it was known that antibodies (Ab) could be used to treat disease in human hosts, and mice were identified as suitable commercial production platforms.

There were two problems linked with this:

  1. i) rejection of mouse Abs by the host; and
    ii) an impaired Ab response in mice transplanted with human Ab genes.

Abs are produced by B-cells and in mice and humans, they carry both, light & heavy chains.
Gene segments for variable regions of Abs comprise variable (V) and joining (J) segments in the light chain locus, and variable (V), diversity (D), and joining (J) segments in the heavy chain locus.

Natural recombination of somatic genes leads to a huge variety of antibodies being produced with different amino acid sequences in the antigen-binding regions, providing a corresponding repertoire of Abs.

INVENTIVE CONCEPT

The solution to the problems associated with the production of Abs in mice was to create a hybrid (chimeric) Ab gene structure, called a “Reverse Chimeric Locus” comprising the murine constant region and the human variable region.

The gene structures are stably integrated into the mouse genome for the production of hybrid antibodies, and mouse constant regions were removed from isolated B-cells prior to mass production.

This enables the production of human Abs that respond naturally to Ag challenge and therefore mimic the natural immune system.

On encountering Ags, B-cells proliferate and differentiate, enabling the production of a diverse spectrum of Abs against an Ag derived single target peptide.

SUFFICIENCY

In accordance with both UK IP law and the EPC, a set of claims to a single product or a range of products is required to be “enabled”, which means that the skilled person must be able to put the invention into effect, with no more than common general knowledge at the priority date, and without “undue experimental burden”.

This is termed the sufficiency requirement of a patent and ensures that the extent of the monopoly granted corresponds to (and does not exceed) the contribution to the art.

HOLDING

The “disclosure in the patent should enable substantially all products within the scope of a product claim to be made by the skilled person at the priority date”. The extent to which the human Ab variable region could be incorporated was understood to be a crucial factor in determining the repertoire of antibodies that could be produced.  The claims conferred a monopoly over mice incorporating any or all of the human variable region when a hybrid gene structure comprising the whole variable region was achieved only with further inventive processes.

Lord Briggs – an invention cannot be considered enabled if it does not permit the skilled person to make it. The invention was held not enabled over “substantially the whole range of products” claimed.

Kymab’s appeal was upheld, and the patents held to be invalid for lack of sufficiency.

The case marks a return to a more traditional approach to sufficiency with far-reaching implications.

PRACTICE TIP

‘The more the better’ when disclosing an invention in a patent application – in the U.S., like the UK’s sufficiency, the law requires the supporting disclosure to be ‘enabling,’ and so an Applicant is best advised to provide every and all inventive aspects of their hoped-for invention.
